Technical specifications
50 | 65 | 80 | 95 | 110 | 125 | 140+1,5xN | ||
---|---|---|---|---|---|---|---|---|
Table width | ||||||||
Surface | mm | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 | 1,750 / 2,500 / 3,000 / 3,500 |
Maximum load on the table | Kg/m2 | 10,000 - 15,000 | ||||||
Turning table | Ø mm | 1,250 - 3,000 | ||||||
Traverses | ||||||||
Longitudinal | X mm | 5,000 | 6,500 | 8,000 | 9,500 | 11,000 | 12,500 | 14,000 |
Cross | Y mm | Transversal: 3,000 - 3,750 - 4,250 - 5,000 / DBC: 2,500 - 3,250 - 3,750 - 4,500 | ||||||
Vertical | Z mm | 1,000 / 1,500 / 1,750 | ||||||
Feeds | ||||||||
Maximum | X m/min | 25 | ||||||
Y m/min | 30 | |||||||
Z m/min | 30 | |||||||
Spindle specifications | ||||||||
Taper | ISO-50 Big Plus / HSK-100 / Capto C8 | |||||||
Programmable speed | rpm | 6,000 / 10.000 | ||||||
Maximum power | kW | 37 / 52 / 42 | ||||||
Maximum torque | Nm | 1,298 / 1,375 / 620 |
